| Product | Character | Typical ffciency | Operating Voltage | Quiescent Iq | Output Voltage | Iq in Shutdown | SW Current Limit | Package | Cross Reference |
|---|---|---|---|---|---|---|---|---|---|
| AP3128A | 1MHz OVP Asynchronous PWM | 92% | 2.5～5.5V | 400μA | Up to 36V | 1μA | 1.2A | SOT23-6L | |
| AP3129A | 1MHz OVP Asynchronous PWM | 92% | 2.5～5.5V | 400μA | Up to 36V | 1μA | 1.2A | TSOT23-6L DFN22-8L | - |
| AP3127B | 1MHz OVP Asynchronous PWM | 88% | 2.5~6V | 550μA | Up to 25V | 1μA | 1A | SOT23-6L | |
| AP3130 | 1MHz OVP Asynchronous PWM | 92% | 2.5~5.5V | 400μA | Up to 36V | <1μA | 1.5A | TSOT23-6L DFN22-8L | - |
| AP3160 | 120kHz Boost Controller for LED Driver | 95% | 9 V ~ 35 V | 800μA | - | 175μA | VCS=400mV (set by CS voltage) | SOP8 | |
| AP3161 | 120kHz Boost Controller for LED Driver | 95% | 9 V ~ 35 V | 800μA | - | 175μA | VCS=400mV (set by CS voltage) | SOP8 | |
| AP3162 | 4CH High Performance LED Driver | 95% | 9 V ~ 30 V | 6mA | - | 20μA | VCS=380mV (set by CS voltage) | SOP16-PP SOP16 TSOP16 |
