高压平面MOS

序号	Part-NO	Package Type	ID(A)	VDss[V]	VGS(th)(V)	RDSON（MAX)(Ω)
1	MOT4512F	TO-220F	12	450	2-4	0.52
2	MOT4512D	TO-252	12	450	2-4	0.52
3	MOT4513A	TO-220	13	450	2-4	0.42
4	MOT4N50SD	TO-252 带快恢复	4	500	2-4	3.5
5	MOT4N50D	TO-252	4	500	2-4	3.5
6	MOT5N50A	TO-220	5	500	2-4	1.6
7	MOT5N50F	TO-220F	5	500	2-4	1.6
8	MOT5N50C	TO-251	5	500	2-4	1.6
9	MOT5N50D	TO-252	5	500	2-4	1.6
10	MOT5N50MD	TO-252	5	500	2-4	2.5
11	MOT5N50XD	TO-252	5	500	2-4	2.9
12	MOT5N50BD	TO-252	5	500	2-4	3.2
13	MOT6N50D	TO-252	6	500	2-4	1.4
14	MOT6N50SD	TO-252	6	500	2-4	1.4
15	MOT9N50A	TO-220	9	500	2-4	0.8
16	MOT9N50F	TO-220F	9	500	2-4	0.8
17	MOT9N50C	TO-251	9	500	2-4	0.8
18	MOT9N50D	TO-252	9	500	2-4	0.8
19	MOT9N50EA	TO-220	9	500	2-4	0.75
20	MOT9N50EF	TO-220F	9	500	2-4	0.75
21	MOT9N50EC	TO-251	9	500	2-4	0.75
22	MOT9N50ED	TO-252	9	500	2-4	0.75
23	MOT10N50A	TO-220	10	500	2-4	0.55
24	MOT10N50F	TO-220F	10	500	2-4	0.55
25	MOT10N50C	TO-251	10	500	2-4	0.55
26	MOT10N50D	TO-252	10	500	2-4	0.55
27	MOT11N50A	TO-220	11	500	2-4	0.55
28	MOT11N50F	TO-220F	11	500	2-4	0.55
29	MOT13N50A	TO-220	13	500	2-4	0.36
30	MOT13N50SF	TO-220F	13	500	2-4	0.55
31	MOT13N50S	TO-252	13	500	2-4	0.36
32	MOT13N50EF	TO-220F	13	500	2-4	0.45
33	MOT13N50F	TO-220F	13	500	2-4	0.42
34	MOT13N50HF	TO-220F	13	500	2-4	0.42
35	MOT15N50A	TO-220	15	500	2-4	0.42
36	MOT15N50HF	TO-220F	15	500	2-4	0.42
37	MOT16N50A	TO-220	16	500	2-4	0.32
38	MOT16N50HF	TO-220F	16	500	2-4	0.32
39	MOT18N50EA	TO-220	18	500	2-4	0.3
40	MOT18N50HF	TO-220F	18	500	2-4	0.3
41	MOT20N50A	TO-220	20	500	2-4	0.25
42	MOT20N50HF	TO-220F	20	500	2-4	0.25
43	MOT20N50W	TO-247S	20	500	2-4	0.25
44	MOT22N50A	TO-220	22	500	2-4.5	0.23
45	MOT22N50HF	TO-220F	22	500	2-4.5	0.23
46	MOT22N50W	TO-247S	22	500	2-4.5	0.23
47	MOT28N50A	TO-220	28	500	2-4.5	0.18
48	MOT28N50HF	TO-220F	28	500	2-4.5	0.18
49	MOT28N50W	TO-247S	28	500	2-4.5	0.18
50	MOT2N60A	TO-220	2	600	2-4	3.4
51	MOT2N60F	TO-220F	2	600	2-4	3.4
52	MOT2N60C	TO-251	2	600	2-4	3.4
53	MOT2N60D	TO-252	2	600	2-4	3.4
54	MOT4N60A	TO-220	4	600	2-4	2.8
55	MOT4N60F	TO-220F	4	600	2-4	2.8
56	MOT4N60C	TO-251	4	600	2-4	2.8
57	MOT4N60D	TO-252	4	600	2-4	2.8
58	MOT5N60A	TO-220	5	600	2-4	2.4
59	MOT5N60F	TO-220F	5	600	2-4	2.4
60	MOT5N60C	TO-251	5	600	2-4	2.4
61	MOT5N60D	TO-252	5	600	2-4	2.4
62	MOT7N60A	TO-220	7	600	2-4	1.3
63	MOT7N60F	TO-220F	7	600	2-4	1.3
64	MOT7N60C	TO-251	7	600	2-4	1.3
65	MOT7N60D	TO-252	7	600	2-4	1.3
66	MOT8N60A	TO-220	8	600	2-4	0.78
67	MOT8N60F	TO-220F	8	600	2-4	0.78
68	MOT8N60C	TO-251	8	600	2-4	0.78
69	MOT8N60D	TO-252	8	600	2-4	0.78
70	MOT10N60A	TO-220	10	600	2-4	0.53
71	MOT10N60F	TO-220F	10	600	2-4	0.53
72	MOT10N60HF	TO-220F	10	600	2-4	0.53
73	MOT10N60C	TO-251	10	600	2-4	0.53
74	MOT10N60D	TO-252	10	600	2-4	0.53
75	MOT12N60A	TO-220	12	600	2-4	0.52
76	MOT12N60HF	TO-220F	12	600	2-4	0.52
77	MOT15N60HF	TO-220F	15	600	2-4	0.5
78	MOT20N60HF	TO-220F	20	600	2-4	0.38
79	MOT22N60A	TO-220	22	600	2-4.5	0.35
80	MOT22N60HF	TO-220F	22	600	2-4.5	0.35
81	MOT22N60W	TO-247S	22	600	2-4.5	0.35
82	MOT28N60A	TO-220	28	600	2-4.5	0.3
83	MOT28N60HF	TO-220F	28	600	2-4.5	0.3
84	MOT28N60W	TO-247S	28	600	2-4.5	0.3
85	MOT2N65A	TO-220	2	650	2-4	5
86	MOT2N65F	TO-220F	2	650	2-4	5
87	MOT2N65C	TO-251	2	650	2-4	5
88	MOT2N65D	TO-252	2	650	2-4	5
89	MOT4N65A	TO-220	4	650	2-4	2.8
90	MOT4N65F	TO-220F	4	650	2-4	2.8
91	MOT4N65C	TO-251	4	650	2-4	2.8
92	MOT4N65D	TO-252	4	650	2-4	2.4
93	MOT5N65A	TO-220	5	650	2-4	2.5
94	MOT5N65F	TO-220F	5	650	2-4	2.4
95	MOT5N65C	TO-251	5	650	2-4	2.4
96	MOT5N65D	TO-252	5	650	2-4	2.4
97	MOT7N65AA	TO-220	7	650	2-4	1.4
98	MOT7N65EA	TO-220	7	650	2-4	1.4
99	MOT7N65YA	TO-220	7	650	2-4	1.4
100	MOT7N65EYA	TO-220	7	650	2-4	1.4
101	MOT7N65AF	TO-220F	7	650	2-4	1.4
102	MOT7N65EF	TO-220F	7	650	2-4	1.4
103	MOT7N65YF	TO-220F	7	650	2-4	1.4
104	MOT7N65EYF	TO-220F	7	650	2-4	1.4
105	MOT7N65AC	TO-251	7	650	2-4	1.4
106	MOT7N65EC	TO-251	7	650	2-4	1.4
107	MOT7N65YC	TO-251	7	650	2-4	1.4
108	MOT7N65EYC	TO-251	7	650	2-4	1.4
109	MOT7N65AD	TO-252	7	650	2-4	1.4
110	MOT7N65ED	TO-252	7	650	2-4	1.4
111	MOT7N65YD	TO-252	7	650	2-4	1.4
112	MOT7N65EYD	TO-252	7	650	2-4	1.4
113	MOT8N65MA	TO-220	8	650	2-4	1.2
114	MOT8N65MF	TO-220F	8	650	2-4	1.2
115	MOT8N65MC	TO-251	8	650	2-4	1.2
116	MOT8N65MD	TO-252	8	650	2-4	1.2
117	MOT8N65F	TO-220F	8	650	2-4	1.2
118	MOT10N65A	TO-220	10	650	2-4	0.82
119	MOT10N65F	TO-220F	10	650	2-4	0.82
120	MOT10N65HF	TO-220F	10	650	2-4	0.82
121	MOT10N65C	TO-251	10	650	2-4	0.82
122	MOT10N65D	TO-252	10	650	2-4	0.82
123	MOT12N65A	TO-220	12	650	2-4	0.65
124	MOT12N65F	TO-220F	12	650	2-4	0.65
125	MOT12N65HF	TO-220F	12	650	2-4	0.65
126	MOT15N65HF	TO-220F	15	650	2-4	0.6
127	MOT16N65A	TO-220	16	650	2-4	0.52
128	MOT16N65HF	TO-220F	16	650	2-4	0.52
129	MOT18N65HF	TO-220F	16	650	2-4	0.52
130	MOT20N65HF	TO-220F	20	650	2-4	0.45
131	MOT22N65A	TO-220	22	650	2-4.5	0.4
132	MOT22N65HF	TO-220F	22	650	2-4.5	0.4
133	MOT22N65W	TO-247S	22	650	2-4.5	0.4
134	MOT28N65A	TO-220	28	650	2-4.5	0.35
135	MOT28N65HF	TO-220F	28	650	2-4.5	0.35
136	MOT28N65W	TO-247S	28	650	2-4.5	0.35
137	MOT2N70A	TO-220	2	700	2-4.5	5
138	MOT2N70F	TO-220F	2	700	2-4.5	5
139	MOT2N70C	TO-251	2	700	2-4.5	5
140	MOT2N70D	TO-252	2	700	2-4.5	5
141	MOT4N70A	TO-220	4	700	2-4.5	2.5
142	MOT4N70F	TO-220F	4	700	2-4.5	2.5
143	MOT4N70C	TO-251	4	700	2-4.5	2.5
144	MOT4N70D	TO-252	4	700	2-4.5	2.5
145	MOT7N70A	TO-220	7	700	2-4.5	1.5
146	MOT7N70F	TO-220F	7	700	2-4.5	1.5
147	MOT7N70C	TO-251	7	700	2-4.5	1.5
148	MOT7N70D	TO-252	7	700	2-4.5	1.5
149	MOT10N70A	TO-220	10	700	2-4.5	1
150	MOT10N70F	TO-220F	10	700	2-4.5	1
151	MOT10N70HF	TO-220F	10	700	2-4.5	1
152	MOT12N70A	TO-220	12	700	2-4.5	0.82
153	MOT12N70F	TO-220F	12	700	2-4.5	0.82
154	MOT12N70HF	TO-220F	12	700	2-4.5	0.82
155	MOT4N80D	TO-252	4	800	2-4	3.8
156	MOT4N80F	TO-220F	4	800	2-4	3.8
157	MOT6N80F	TO-220F	6	800	2-4	2.3
158	MOT7N80F	TO-220F	7	800	2-5	1.8
159	MOT8N80HF	TO-220F	9	800	2-4	1
160	MOT10N80HF	TO-220F	10	800	2-5	0.75
161	MOT12N80HSF	TO-220F	12	800	2-5	0.73
162	MOT14N80N	TO-247	14	800	2-4	0.72
163	MOT27N80N	TO-247	27	800	2-5	0.35
164	MOT3N90D	TO-252	3	900	2-5	4.75
165	MOT3N90F	TO-220F	3	900	2-5	4.75
166	MOT4N90D	TO-252	4	900	2-5	4.8
167	MOT4N90F	TO-220F	4	900	2-5	4.8
168	MOT6N90F	TO-220F	6	900	2-5	1.6
169	MOT9N90F	TO-220F	9	900	2-5	1.35
170	MOT9N90AF	TO-220F	9	900	2-4	1
171	MOT12N90N	TO-247	12	900	2-4	1
172	MOT12N90W	TO-247S	12	900	2-4	1
173	MOT18N90N	TO-247	18	900	2-4	0.78
174	MOT18N90W	TO-247S	18	900	2-4	0.78
175	MOT24N90N	TO-247	24	900	2-5	0.42
176	MOT24N90W	TO-247S	24	900	2-5	0.42
177	MOT1N100F	TO-220F	0.5	1000	2-4	55
178	MOT2N100D	TO-252	2	1000	2-4	8.8
179	MOT4N100D	TO-252	4	1000	2-4	2.5
180	MOT4N100F	TO-220F	4	1000	2-4	2.5
181	MOT6N100F	TO-220F	6	1000	2-5	2.3
182	MOT9N100F	TO-220F	9	1000	2-4	1.5
183	MOT10N100F	TO-220F	10	1000	2-5	1.25
184	MOT13N100F	TO-220F	13	1000	2-5	1.4
185	MOT24N100N	TO-247	24	1000	2-5	0.45
186	MOT3N120D	TO-252	3	1200	2-5	8
187	MOT3N120F	TO-220F	3	1200	2-5	8
188	MOT10N120F	TO-220F	10	1200	2-5	4.2
189	MOT10N120AF	TO-220F	10	1200	2-5	1.9
190	MOT3N150F	TO-220F	3	1500	2-5	8.2
191	MOT3N150V	TO-3PH	3	1500	2-5	8.2
192	MOT9N150N	TO-247	9	1500	2-5	4
193	MOT11N150N	TO-247	11	1500	2-5	3.7
194	MOT20N65N	TO-247	20	650	2-4	0.36
195	MOT40N50N	TO-247	40	500	2-4	0.11
196	MOT30N50N	TO-247	30	500	2-4	0.22
197	MOT25N50N	TO-247	25	500	2-4	0.26
198	MOT50215SG	PDFN5*6	5	500	2-4	1.8
199	MOT50221G	PDFN5*6	5	500	2-4	2.1
200	MOT50232G	PDFN5*6	5	500	2-4	3.2
201	MOT20N65Q	TO-3PB	20	650	2-4	0.36
202	MOT9N90Q	TO-3PB	9	900	3-5	1.6
203	MOT16N65E	TO-263	16	650	2-4	0.5
204	MOT12N65E	TO-263	12	650	2-4	0.7
205	MOT7N65EE	TO-263	7	650	2-4	1.35
206	MOT5N65EE	TO-263	5	650	2-4	2.8
207	MOT740F	TO-220F	10	400	2-4	0.53
208	MOT150N15N	TO-247	157	150	2.5-4.5	0.0062
209	MOT25N50W	TO-247S	25	500	2-4	0.26
210	MOT28N50Q	TO-3PB	28	500	2-4	0.22
211	MOT65R180	TO-220F	20	650	2-4	0.18
212	MOT50N50N	TO-247	50	500	2-4	0.08
213	MOT5N50CSD	TO-252	5	500	2-4	3.5
213	MOT40N50N	TO-247	40	500	2-4	0.16
